OPB365T55 Optek, Screw Mount Slotted Optical Switch, Phototransistor Output
技術文件
規格
Brand
OptekOutput Device
Phototransistor
Number of Channels
1
Typical Rise Time
10µs
Mounting Type
Screw Mount
Number of Pins
4
Dimensions
24.61 x 6.35 x 10.8mm
Height
10.8mm
Length
24.61mm
Maximum Operating Temperature
+85°C
Minimum Operating Temperature
-40°C
Slot Width
3.18mm
Width
6.35mm
Operating Temperature Range
-40 → +85°C
原產地
Mexico
產品詳情
OPB355/360/370/380/390 Series Slotted Optical Switches
This family of slotted optical sensors from Optek Technology enables you to create a custom device from a standard product line. This flexibility includes choices of slot width, aperture, shell material, mounting configurations and lead spacing, or wires. An opaque plastic housing minimises the sensitivity to visible and near IR light.
The parallel faces inside the slot are covered with an IR transmissive plastic or opaque plastic with an opening. The IR transmissive plastic is suitable for applications which require dust protection and the opaque is for applications that require maximum protection against ambient light.
The OPB360, OPB370, OPB380 and OPB390 utilise a phototransistor sensor. The OPB355 has a photodiode sensor. Suitable applications for the slotted optical switches include; non-contact object sensing, assembly line automation, machine automation, equipment safety and machine safety.
Slotted Optical Switches, Optek Technology
醞釀。 創造。 合作
免費加入
無隱藏費用！
- 下載並使用我們的 DesignSpark 軟體進行 PCB 和 3D 機械設計
- 查看網站內容和論壇
- 下載超過一百萬種產品的 3D 模型、原理圖和封裝
33.20 MOP
33.18 MOP Each (不含稅)
1
33.20 MOP
33.18 MOP Each (不含稅)
暫時無法取得庫存資訊。
1
暫時無法取得庫存資訊。
| 數量 | 單價 |
|---|---|
| 1 - 4 | 33.18 MOP |
| 5+ | 32.46 MOP |
