RS PRO Axial Fan, 12 V dc, DC Operation, 23.8m³/h, 1.3W, 80mA Max, 60 x 60 x 15mm
技術文件
規格
Brand
RS ProSupply Voltage
12 V dc
AC or DC Operation
DC
Height
60mm
Width
60mm
Power Consumption
1.3W
Maximum Current
80mA
Depth
15mm
Termination Type
Lead Wire
Dimensions
60 x 60 x 15mm
Air Flow
23.8m³/h
Noise Level
29dB
Fan Speed
3900rpm
Direction of Curve
Backward
Bearing Type
Ball
原產地
China
產品詳情
RS Brushless High Performance Ball Bearing Fan
RS PRO Brushless High-Performance Ball Bearing Axial Fan
Brought to you by RS PRO, this high-performance ball bearing axial fan offers a cost-effective cooling solution without sacrificing on quality or reliability. With a robust plastic frame and impeller, the fan is perfect for lightweight applications where ventilation and cooling are required. The fan has a brushless DC motor which reduces the chance of overheating while delivering a high-speed high-pressure output.
Approvals
UL, cUL, TUV
70.00 MOP
69.97 MOP Each (不含稅)
1
70.00 MOP
69.97 MOP Each (不含稅)
暫時無法取得庫存資訊。
1
暫時無法取得庫存資訊。
| 數量 | 單價 |
|---|---|
| 1 - 4 | 69.97 MOP |
| 5 - 9 | 69.76 MOP |
| 10 - 24 | 66.98 MOP |
| 25 - 124 | 64.41 MOP |
| 125+ | 63.17 MOP |
