EPCOS, B84112G 16A 250 V ac/dc 50 → 60Hz, Chassis Mount EMC Filter, Screw, Single Phase

RS Stock No.: 496-4778Brand: EPCOSManufacturers Part No.: B84112G0000B116Distrelec Article No.: 30203625
brand-logo
View all in Power Line Filters

Technical Document

Specifications

Brand

Epcos

Maximum Current Rating

16A

Maximum Voltage Rating

250 V ac/dc

Mounting Type

Chassis Mount

Termination Style

Screw

Number of Phases

1

Number of Stages

Single Stage

Series

B84112G

Operating Frequency

50 → 60Hz

Length

89.5mm

Depth

52mm

Height

29mm

Capacitance

2 x 0.47 μF, 2 x 4700pF

Dimensions

89.5 x 52 x 29mm

Inductance

2 x 1.8 mH

Minimum Operating Temperature

-25°C

Leakage Current

0.369 mA

Maximum Operating Temperature

+100°C

Standards Met

UL 1283

Product details

B84112-G Series

TDK B84112-G Series are power filters for single phase systems. Compact in design and easy to install, Constricted of 2 line filters and a metal case.SIFI-G for enhanced insertion loss. Rated voltage VR: 250 V AC/DC.Rated current IR: 2 A to 36 A

Applications

Industrial electronics
Switch-mode power supplies
Telecom systems
Data systems
DC applications
Medical equipment (version B84112G0000M*)
