Finder 85 Series Series Plug In Timer Relay, 24V ac/dc, 4-Contact, 0.05 → 100 s, 3 → 100 min, 5 →
Technical Document
Specifications
Brand
FinderSupply Voltage
24V ac/dc
Mounting Type
Plug In
Mode of Operation
Interval, ON Delay, Pulse Delayed, Symmetrical Flasher
Time Range
0.05 → 100 s, 3 → 100 min, 5 → 100h
Number of Contacts
4
Number of Timer Functions
Multi Function
Contact Configuration
4PDT
Time Increment
Hours, Minutes, Seconds
Maximum Current
7A
Maximum Voltage
250V ac
Switch Configuration
4PDT
Terminal Type
14-Pin Connector
Power Supply
External
Width
20.6mm
Minimum Current
10A
Length
59.5mm
Series
85 Series
Depth
27.7mm
Maximum Operating Temperature
+60°C
Contact Material
Silver Nickel
Minimum Operating Temperature
-20°C
Time Delay
<=20ms
Country of Origin
Italy
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
482.50 MOP
482.48 MOP Each (ex VAT)
1
482.50 MOP
482.48 MOP Each (ex VAT)
Stock information temporarily unavailable.
1
| quantity | Unit price |
|---|---|
| 1 - 24 | 482.48 MOP |
| 25 - 49 | 458.47 MOP |
| 50+ | 443.94 MOP |
