Omron Power Relay, 24V dc Coil, 5A Switching Current, 4PDT

RS Stock No.: 794-8145Brand: OmronManufacturers Part No.: MY4IN1 24VDC (S)
brand-logo
View all in Power Relays

Technical Document

Specifications

Brand

Omron

Product Type

Power Relay

Coil Voltage

24V dc

Contact Configuration

4PDT

Series

MY4

Terminal Type

Plug-In

Switching Current

5A

Minimum Operating Temperature

-55°C

Switching Power

0.9W

Switching DC Voltage

125V dc

Switching AC Voltage

125V ac

Coil Resistance

636Ω

Maximum Operating Temperature

70°C

Height

28mm

Coil Power

900mW

Length

36mm

Standards/Approvals

UL, CSA

Width

21.5mm

Contact Material

Silver Alloy

Contact Resistance

50mΩ

Country of Origin

Japan

Product details

MY Series

Switch power: 10A version: 1100W, 5A version 660W
Contact resistance: 100mΩ
Isolation coil to contact: 2000Vac
Operating temperature range: -55 to +70°C
Maximum switching voltage: 250Vac; 125Vdc
Contact material: AgNi
Dimensions: H42.4mm x W21.5mm x D28mm

Approvals

VDE, UL, CSA
