onsemi Triple Switching Diode, Isolated, 100mA 80V, 6-Pin SOT-363 HN2D02FUTW1T1G

RS Stock No.: 808-0041Brand: onsemiManufacturers Part No.: HN2D02FUTW1T1G
brand-logo
View all in Switching Diodes

Technical Document

Specifications

Brand

onsemi

Maximum Forward Current

100mA

Diode Configuration

Isolated

Number of Elements per Chip

3

Mounting Type

Surface Mount

Maximum Reverse Voltage

80V

Package Type

SOT-363 (SC-88)

Diode Technology

Silicon Junction

Pin Count

6

Maximum Forward Voltage Drop

1.2V

Maximum Diode Capacitance

2pF

Maximum Operating Temperature

+150 °C

Length

2.2mm

Width

1.35mm

Height

1mm

Dimensions

2.2 x 1.35 x 1mm

Product details

Small Signal Switching Diodes, ON Semiconductor

Standards

Products with S-prefixed Manufacturer Part Nos are AEC-Q101 automotive qualified.
