onsemi MC14001BDR2G, Quad 2-Input NOR Logic Gate, 14-Pin SOIC
Technical Document
Specifications
Brand
onsemiLogic Function
NOR
Mounting Type
Surface Mount
Number Of Elements
4
Number of Inputs per Gate
2
Schmitt Trigger Input
No
Package Type
SOIC
Pin Count
14
Logic Family
4000
Input Type
CMOS
Maximum Operating Supply Voltage
18 V
Maximum High Level Output Current
-4.2mA
Maximum Propagation Delay Time @ Maximum CL
350ns
Minimum Operating Supply Voltage
0.5 V
Maximum Low Level Output Current
4.2mA
Height
1.5mm
Width
4mm
Minimum Operating Temperature
-55 °C
Dimensions
8.75 x 4 x 1.5mm
Maximum Operating Temperature
+125 °C
Propagation Delay Test Condition
50pF
Length
8.75mm
Product details
4000 Series Logic Gates, ON Semiconductor
4000 CMOS Logic Family, ON Semiconductor
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
3,952.00 MOP
1.581 MOP Each (On a Reel of 2500) (ex VAT)
2500
3,952.00 MOP
1.581 MOP Each (On a Reel of 2500) (ex VAT)
Stock information temporarily unavailable.
2500
| quantity | Unit price | Per Reel |
|---|---|---|
| 2500 - 2500 | 1.581 MOP | 3,951.97 MOP |
| 5000 - 7500 | 1.533 MOP | 3,833.46 MOP |
| 10000+ | 1.487 MOP | 3,718.35 MOP |
