Technical Documents
Specifications
Brand
SchurterProduct Type
Panel Mount Fuse Holder
Number of Poles
1
Body Material
Black, Thermoplastic
IP Rating
IP40
Compatible Fuse Size
5 x 20 mm
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Standards/Approvals
CSA 22.2 no. 4248.1, IEC 60127-6, UL 4248-1
Protection Category
PC3
Cap Style
Manual
Series
FBS
Contact Material
Tin Plated Copper
Product Details
CATEGORIES OF PROTECTION AGAINST ELECTRIC SHOCK,PC1: No integral protection against electric shock. If required, designers must provide additional protection against electric shock on equipment.,PC2: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 standard test finger, when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.,PC3: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 1mm diameter rigid test wire when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.
VDE, UL, CSA
Stock information temporarily unavailable.
212.40 MOP
42.477 MOP Each (In a Pack of 5) (ex VAT)
5
212.40 MOP
42.477 MOP Each (In a Pack of 5) (ex VAT)
Stock information temporarily unavailable.
5
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 45 | 42.477 MOP | 212.39 MOP |
| 50 - 245 | 41.199 MOP | 206.00 MOP |
| 250 - 495 | 39.963 MOP | 199.81 MOP |
| 500 - 1245 | 39.077 MOP | 195.38 MOP |
| 1250+ | 38.376 MOP | 191.88 MOP |
