Technical Documents
Specifications
Brand
Allegro MicrosystemsProduct Type
Hall Effect Sensor
Sensor Type
Hall Effect Sensors
Number of Axis
2
Technology
BiCMOS, Planar and Vertical Hall Element
Mount Type
Surface
Magnetic Type
Latch
Minimum Supply Voltage
4V
Package Type
SOT-23W
Maximum Supply Voltage
24V
Minimum Operating Temperature
-40°C
Pin Count
5
Maximum Operating Temperature
150°C
Length
2.98mm
Height
0.95mm
Standards/Approvals
Lead (Pb) Free, RoHS
Series
A1262
Supply Current
4.5mA
Automotive Standard
AEC-Q100
Response Time
32μs
Country of Origin
Philippines
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
3,565.20 MOP
7.13 MOP Each (On a Reel of 500) (ex VAT)
500
3,565.20 MOP
7.13 MOP Each (On a Reel of 500) (ex VAT)
Stock information temporarily unavailable.
500
| quantity | Unit price | Per Reel |
|---|---|---|
| 500 - 2000 | 7.13 MOP | 3,565.22 MOP |
| 2500+ | 6.917 MOP | 3,458.36 MOP |
