Technical Documents
Specifications
Brand
BroadcomProduct Type
Optocoupler
Mount Type
Through Hole
Maximum Forward Voltage
1.75V
Packaging
Tube
Number of Channels
1
Number of Pins
8
Package Type
DIP
Input Current Type
DC
Maximum Input Current
12mA
Isolation Voltage
3750Vrms
Minimum Operating Temperature
-45°C
Logic Output
Yes
Maximum Current Transfer Ratio
50%
Maximum Operating Temperature
80°C
Minimum Current Transfer Ratio
400%
Standards/Approvals
EN, IEC, UL, CSA
Series
6N139
Automotive Standard
No
Product Details
This range of optocouplers with darlington output, from Avago Technologies, offer a high current transfer ratio with low input current requirements. The optocoupler devices use light emitting diodes (LEDs) optically coupled with integrated high gain photodetectors. They provide excellent input-output common mode transient immunity and guaranteed performance over temperatures of 0 to 70°C.
Stock information temporarily unavailable.
72.30 MOP
7.234 MOP Each (In a Pack of 10) (ex VAT)
Standard
10
72.30 MOP
7.234 MOP Each (In a Pack of 10) (ex VAT)
Stock information temporarily unavailable.
Standard
10
| quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 10 | 7.234 MOP | 72.34 MOP |
| 20 - 20 | 7.08 MOP | 70.80 MOP |
| 30+ | 6.935 MOP | 69.35 MOP |
