Technical Documents
Specifications
Brand
BroadcomMount Type
Surface
Product Type
Optocoupler
Maximum Forward Voltage
5.5V
Number of Channels
1
Packaging
Tape & Reel
Number of Pins
8
Package Type
DIP
Input Current Type
DC
Typical Rise Time
2.96μs
Maximum Input Current
400mA
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
125°C
Typical Fall Time
2.96μs
Standards/Approvals
DIN EN 60747-5-2 UL CSA, IEC 60747-5-5
Series
ACPL-782T
Automotive Standard
AEC-Q100
Product Details
The Broadcom ACPL-782T automotive isolation amplifier family was designed for current sensing in electronic motor drives and battery system. In a typical implementation, motor currents or battery current flow through an external resistor and the resulting analog voltage drop is sensed by the ACPL-782T. A differential output voltage is created on the other side of the ACPL-782T optical isolation barrier. This differential output voltage is proportional to the motor current and can be converted to a single-ended signal by using an op-amp as shown in the recommended application circuit.
Stock information temporarily unavailable.
62,794.00 MOP
62.794 MOP Each (On a Reel of 1000) (ex VAT)
1000
62,794.00 MOP
62.794 MOP Each (On a Reel of 1000) (ex VAT)
Stock information temporarily unavailable.
1000
| quantity | Unit price | Per Reel |
|---|---|---|
| 1000 - 1000 | 62.794 MOP | 62,794.03 MOP |
| 2000 - 9000 | 61.538 MOP | 61,538.06 MOP |
| 10000+ | 60.307 MOP | 60,307.23 MOP |
