HARWIN M52 Series Straight Surface PCB Socket, 10-Contact, 1 Row, 1.27 mm Pitch Solder

Name: HARWIN M52 Series Straight Surface PCB Socket, 10-Contact, 1 Row, 1.27 mm Pitch Solder
Brand: HARWIN
SKU: 6813063P
Availability: LimitedAvailability

RS Stock No.: 681-3063PBrand: HARWINManufacturers Part No.: M52-5051045

View all in PCB Sockets

Technical Documents

Specifications

Brand

HARWIN

Number of Contacts

Product Type

PCB Socket

Sub Type

Socket Strip

Number of Rows

Pitch

1.27mm

Current

12A

Termination Type

Solder

Housing Material

Nylon

Mount Type

Surface

Orientation

Straight

Connector System

Board-to-Board

Voltage

500V

Series

M52

Minimum Operating Temperature

-40°C

Contact Gender

Female

Maximum Operating Temperature

105°C

Contact Material

Bronze

Contact Plating

Gold

Standards/Approvals

Country of Origin

Taiwan, Province Of China

Product Details

Shrouded Socket and Pin Headers

M50-300/310/311/315/320 Series socket headers mate with M50-350/360/390 Series unshrouded headers typical stock number 681-1184
M52-500/505/510/515 Series socket headers mate with M52-xxxxxxP/S/V/Wxxxx Series unshrouded headers typical stock number 681-3001
M50-430 Series socket headers mate with M50-490 Series pin headers

1.27mm Harwin M50 Series
