Maxim Integrated Line Transceiver, CMOS, Inverting, 28-Pin SOIC

RS Stock No.: 190-6149Brand: Maxim IntegratedManufacturers Part No.: MAX211CWI+
brand-logo
View all in Line Interface ICs

Technical Document

Specifications

Brand

Maxim Integrated

Logic Family

CMOS/TTL

Product Type

Line Transceiver

Logic Function

Converter, Driver, Line Driver

IC Type

Line Transceiver IC

Input Type

Single Ended

Output Type

CMOS

Polarity

Inverting

Mount Type

Surface

Package Type

SOIC

Minimum Supply Voltage

-0.3V

Pin Count

28

Maximum Supply Voltage

5V

Maximum High Level Output Current

60mA

Maximum Low Level Output Current

10mA

Maximum Propagation Delay Time @ CL

10μs

Minimum Operating Temperature

0°C

Maximum Operating Temperature

70°C

Width

10.65 mm

Height

2.65mm

Length

18.1mm

Standards/Approvals

No

Series

MAX211

Supply Current

20mA

Automotive Standard

No

View all in Line Interface ICs

Stock information temporarily unavailable.

1,976.20 MOP

79.048 MOP Each (In a Tube of 25) (ex VAT)

Maxim Integrated Line Transceiver, CMOS, Inverting, 28-Pin SOIC

25

Available in multiples of 25
251,976.20 MOP
503,952.40 MOP
755,928.60 MOP
1007,904.80 MOP
1259,683.10 MOP
15011,619.70 MOP
17513,556.30 MOP
20015,492.90 MOP
22517,429.60 MOP
25019,366.20 MOP
27521,302.80 MOP
30023,239.40 MOP
32525,176.00 MOP
35027,112.70 MOP
37529,049.30 MOP

1,976.20 MOP

79.048 MOP Each (In a Tube of 25) (ex VAT)

Maxim Integrated Line Transceiver, CMOS, Inverting, 28-Pin SOIC

Stock information temporarily unavailable.

25

Available in multiples of 25
251,976.20 MOP
503,952.40 MOP
755,928.60 MOP
1007,904.80 MOP
1259,683.10 MOP
15011,619.70 MOP
17513,556.30 MOP
20015,492.90 MOP
22517,429.60 MOP
25019,366.20 MOP
27521,302.80 MOP
30023,239.40 MOP
32525,176.00 MOP
35027,112.70 MOP
37529,049.30 MOP

quantityUnit pricePer Tube
25 - 10079.048 MOP1,976.19 MOP
125+77.465 MOP1,936.62 MOP
