Molex iGrid 2.0 Series Right Angle Through Hole PCB Header, 28 Contact(s), 2 mm Pitch, 2 Row, Shrouded

RS Stock No.: 201-7976Brand: MolexManufacturers Part No.: 2086592840Distrelec Article No.: 304-62-136
brand-logo
View all in PCB Headers

Technical Document

Specifications

Brand

Molex

Series

iGrid 2.0

Product Type

PCB Header

Pitch

2mm

Current

2A

Number of Contacts

28

Housing Material

Polyamide

Number of Rows

2

Orientation

Right Angle

Shrouded/Unshrouded

Shrouded

Connector System

Wire-to-Board

Mount Type

Through Hole

Contact Material

Brass

Contact Plating

Gold

Minimum Operating Temperature

-40°C

Row Pitch

2mm

Termination Type

Solder

Contact Gender

Male

Tail Pin Length

3.2mm

Maximum Operating Temperature

105°C

Standards/Approvals

UL E29179

Voltage

250 V

Country of Origin

Japan
