Molex iGrid Series Vertical Through Hole PCB Header, 36 Contact(s), 2 mm Pitch, 2 Row, Shrouded

RS Stock No.: 213-4630Brand: MolexManufacturers Part No.: 5016453620Distrelec Article No.: 304-56-388
brand-logo
View all in PCB Headers

Technical Document

Specifications

Brand

Molex

Series

iGrid

Product Type

PCB Header

Pitch

2mm

Current

2A

Number of Contacts

36

Housing Material

Nylon

Number of Rows

2

Orientation

Vertical

Shrouded/Unshrouded

Shrouded

Connector System

iGrid Wire to Board Dual Row System

Mount Type

Through Hole

Contact Material

Brass

Contact Plating

Tin

Minimum Operating Temperature

-40°C

Row Pitch

2mm

Termination Type

Solder

Contact Gender

Male

Tail Pin Length

3.2mm

Maximum Operating Temperature

105°C

Standards/Approvals

CSA LR19980, UL E29179

Voltage

250 V

Country of Origin

Vietnam
