Molex Pico-Lock Series Right Angle Surface PCB Header, 12 Contact(s), 1.5 mm Pitch, 1 Row, Shrouded

RS Stock No.: 243-6909PBrand: MolexManufacturers Part No.: 504050-1291
brand-logo
View all in PCB Headers

Technical Document

Specifications

Brand

Molex

Series

Pico-Lock

Product Type

PCB Header

Pitch

1.5mm

Current

2A

Number of Contacts

12

Housing Material

High Temperature Thermoplastic

Number of Rows

1

Orientation

Right Angle

Shrouded/Unshrouded

Shrouded

Connector System

Wire-to-Board

Mount Type

Surface

Contact Material

Copper Alloy

Contact Plating

Gold

Minimum Operating Temperature

-40°C

Row Pitch

1.5mm

Termination Type

Surface Mount

Contact Gender

Male

Maximum Operating Temperature

105°C

Mating Pin Length

2mm

Standards/Approvals

CSA LR19980, UL E29179

Voltage

150 Vrms

Country of Origin

Malaysia
