Molex Micro-Lock Plus Series Straight Surface PCB Header, 4 Contact(s), 2 mm Pitch, 1 Row(s), Shrouded

RS Stock No.: 186-5052Brand: MolexManufacturers Part No.: 505575-0471
brand-logo
View all in PCB Headers

Technical Document

Specifications

Brand

Molex

Series

Micro-Lock Plus

Product Type

PCB Header

Pitch

2mm

Current

3A

Number of Contacts

4

Housing Material

Polyamide

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Shrouded

Connector System

Wire-to-Board

Mount Type

Surface

Contact Material

Brass

Contact Plating

Tin

Minimum Operating Temperature

-40°C

Row Pitch

2mm

Termination Type

Solder

Contact Gender

Male

Maximum Operating Temperature

125°C

Standards/Approvals

No

Voltage

250 V

Distrelec Product Id

304-57-356

Ideate. Create. Collaborate

JOIN FOR FREE

No hidden fees!

design-spark
design-spark
  • Download and use our DesignSpark software for your PCB and 3D Mechanical designs
  • View and contribute website content and forums
  • Download 3D Models, Schematics and Footprints from more than a million products
Click here to find out more

Stock information temporarily unavailable.

3,567.10 MOP

5.945 MOP Each (On a Reel of 600) (ex VAT)

Molex Micro-Lock Plus Series Straight Surface PCB Header, 4 Contact(s), 2 mm Pitch, 1 Row(s), Shrouded

600

Available in multiples of 600
6003,567.10 MOP
12006,991.50 MOP
180010,487.30 MOP
240013,703.20 MOP
300017,129.00 MOP
360020,554.80 MOP
420023,980.60 MOP
480027,406.40 MOP
540030,832.10 MOP
600034,257.90 MOP
660037,683.70 MOP
720041,109.50 MOP
780044,535.30 MOP
840047,961.10 MOP
900051,386.90 MOP

3,567.10 MOP

5.945 MOP Each (On a Reel of 600) (ex VAT)

Molex Micro-Lock Plus Series Straight Surface PCB Header, 4 Contact(s), 2 mm Pitch, 1 Row(s), Shrouded

Stock information temporarily unavailable.

600

Available in multiples of 600
6003,567.10 MOP
12006,991.50 MOP
180010,487.30 MOP
240013,703.20 MOP
300017,129.00 MOP
360020,554.80 MOP
420023,980.60 MOP
480027,406.40 MOP
540030,832.10 MOP
600034,257.90 MOP
660037,683.70 MOP
720041,109.50 MOP
780044,535.30 MOP
840047,961.10 MOP
900051,386.90 MOP

quantityUnit pricePer Reel
600 - 6005.945 MOP3,567.08 MOP
1200 - 18005.826 MOP3,495.76 MOP
2400+5.71 MOP3,425.79 MOP
