Technical Documents
Specifications
Brand
onsemiDiode Configuration
Complex Array
Product Type
TVS Diode Array
Direction Type
Uni-Directional
Minimum Breakdown Voltage Vbr
5.5V
Mount Type
Surface
Package Type
SOT-553
Maximum Reverse Stand-off Voltage Vwm
5.5V
Pin Count
6
Clamping Voltage VC
10V
Minimum Operating Temperature
-40°C
Test Current It
1mA
Maximum Peak Pulse Current Ippm
12A
ESD Protection
Yes
Number of Elements per Chip
4
Maximum Operating Temperature
125°C
Height
0.6mm
Length
1.7mm
Standards/Approvals
No
Width
1.3mm
Maximum Reverse Leakage Current
1μA
Automotive Standard
AEC-Q101
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
118.70 MOP
4.749 MOP Each (Supplied on a Reel) (ex VAT)
Production pack (Reel)
25
118.70 MOP
4.749 MOP Each (Supplied on a Reel) (ex VAT)
Stock information temporarily unavailable.
Production pack (Reel)
25
| quantity | Unit price | Per Reel |
|---|---|---|
| 25 - 975 | 4.749 MOP | 118.71 MOP |
| 1000 - 1975 | 4.633 MOP | 115.83 MOP |
| 2000+ | 4.555 MOP | 113.87 MOP |
