RS PRO Circular Connector, 5 Contacts, Cable, M12 Connector, Socket, Male, IP67, SF12 Series

Name: RS PRO Circular Connector, 5 Contacts, Cable, M12 Connector, Socket, Male, IP67, SF12 Series
Brand: RS PRO
SKU: 1246721
Availability: LimitedAvailability

RS Stock No.: 124-6721Brand: RS PRO

View all in Industrial Circular Connectors

Technical Documents

Specifications

Brand

RS Pro

Number of Contacts

Product Type

Circular Connector

Mount Type

Cable

Connector Size

M12

Current

Plug/Socket

Socket

Contact Gender

Male

IP Rating

IP67

Series

SF12

Orientation

Straight

Voltage

180V

Mating Type

Push Pull

Minimum Operating Temperature

-40°C

Termination Type

Solder

Maximum Operating Temperature

85°C

Housing Material

Chrome Plated Brass

Pole Format

Standards/Approvals

Contact Plating

Gold

Contact Material

Brass

Country of Origin

China

Product Details

M12 In-Line Push-Pull Cable Socket

From RS Pro, these push-pull sockets are serious contenders for your application. The convenient push-pull connection, makes it perfect in situations where accidental disconnects occur. That coupled with the IP67 rating, makes sure that this industrial connector excels in harsh environments. When choosing a female connector, this version should really be one you consider.

Features & Benefits

• Panel hole cutout diameter: 12 mm
• 2 way, 3 way, 4 way and 5 way all available
• Cable outer diameter: 4 mm to 6.5 mm see part numbers
124-6713 124-6714 124-6715 124-6716
• Cable outer diameter: 5 mm to 8 mm
124-6717 124-6719 124-6720 124-6721
• Solder termination
• Chrome plated brass shell material
• Inline cable mounted
