RS PRO Plunger Micro Switch, Quick Connect Terminal, 6 A, 400 V ac, SPDT, IP40

RS Stock No.: 804-6231Brand: RS PRO
brand-logo
View all in Micro Switches

Technical Document

Specifications

Brand

RS Pro

Product Type

Micro Switch

Actuator Type

Plunger

Terminal Type

Quick Connect

Switch Contact Current

6 A

Contact Configuration

SPDT

IP Rating

IP40

Operating Force

600g

Minimum Operating Temperature

-20°C

Maximum Operating Temperature

85°C

Contact AC Voltage

400V ac

Width

13 mm

Length

30mm

Mechanical Life

1000000Cycles

Hazardous Area Certification

No

Standards/Approvals

IEC 1058-1, CE, RoHS, CSA

Country of Origin

India

View all in Micro Switches

Stock information temporarily unavailable.

79.30 MOP

79.35 MOP Each (ex VAT)

RS PRO Plunger Micro Switch, Quick Connect Terminal, 6 A, 400 V ac, SPDT, IP40

1

Available in multiples of 1
179.30 MOP
2158.70 MOP
3238.00 MOP
4317.40 MOP
5396.70 MOP
6476.10 MOP
7555.40 MOP
8634.80 MOP
9714.10 MOP
10793.50 MOP
11872.80 MOP
12952.20 MOP
131,031.50 MOP
141,110.90 MOP
151,190.20 MOP

79.30 MOP

79.35 MOP Each (ex VAT)

RS PRO Plunger Micro Switch, Quick Connect Terminal, 6 A, 400 V ac, SPDT, IP40

Stock information temporarily unavailable.

1

Available in multiples of 1
179.30 MOP
2158.70 MOP
3238.00 MOP
4317.40 MOP
5396.70 MOP
6476.10 MOP
7555.40 MOP
8634.80 MOP
9714.10 MOP
10793.50 MOP
11872.80 MOP
12952.20 MOP
131,031.50 MOP
141,110.90 MOP
151,190.20 MOP

quantityUnit price
1 - 1979.35 MOP
20 - 4976.98 MOP
50 - 14974.61 MOP
150 - 74973.06 MOP
750+60.08 MOP

Technical Document

Specifications

Brand

RS Pro

Product Type

Micro Switch

Actuator Type

Plunger

Terminal Type

Quick Connect

Switch Contact Current

6 A

Contact Configuration

SPDT

IP Rating

IP40

Operating Force

600g

Minimum Operating Temperature

-20°C

Maximum Operating Temperature

85°C

Contact AC Voltage

400V ac

Width

13 mm

Length

30mm

Mechanical Life

1000000Cycles

Hazardous Area Certification

No

Standards/Approvals

IEC 1058-1, CE, RoHS, CSA

Country of Origin

India
