Samtec BCS Series Straight Through Hole PCB Socket, 10-Contact, 1 Row, 2.54 mm Pitch Solder
Technical Document
Specifications
Brand
SamtecNumber of Contacts
10
Product Type
PCB Socket
Number of Rows
1
Sub Type
Socket Strip
Pitch
2.54mm
Current
5.9A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Through Hole
Orientation
Straight
Connector System
Board-to-Board
Voltage
475 V
Series
BCS
Minimum Operating Temperature
-55°C
Row Pitch
0.1in
Maximum Operating Temperature
125°C
Contact Material
Bronze
Contact Plating
Gold
Standards/Approvals
CHINA RoHS, EU REACH, EU RoHS
Product details
2.54mm Through Hole Connectors - PC104 Range
A range of through hole PCB connectors that allow for the interconnection and vertical stacking of PCBs.
Single or double row Vertical headers
Operating temperature range -65 to +125°C
2.54mm Board to Board and Wire to Board - Samtec
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
21.60 MOP
21.64 MOP Each (ex VAT)
1
21.60 MOP
21.64 MOP Each (ex VAT)
Stock information temporarily unavailable.
1
| quantity | Unit price |
|---|---|
| 1 - 19 | 21.64 MOP |
| 20 - 74 | 20.98 MOP |
| 75 - 299 | 20.34 MOP |
| 300 - 599 | 19.91 MOP |
| 600+ | 19.48 MOP |
