Technical Documents
Specifications
Brand
SamtecNumber of Contacts
120
Product Type
PCB Socket
Number of Rows
2
Sub Type
Board-to-Board
Pitch
0.5mm
Current
12A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Surface
Orientation
Right Angle
Stacking Height
5mm
Connector System
Board-to-Board
Voltage
175V
Series
BSH
Minimum Operating Temperature
-55°C
Row Pitch
5.73mm
Maximum Operating Temperature
125°C
Contact Material
Bronze
Contact Plating
Gold
Standards/Approvals
No
Country of Origin
Costa Rica
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
3,925.60 MOP
52.341 MOP Each (In a Tray of 75) (ex VAT)
75
3,925.60 MOP
52.341 MOP Each (In a Tray of 75) (ex VAT)
Stock information temporarily unavailable.
75
| quantity | Unit price | Per Tray |
|---|---|---|
| 75 - 75 | 52.341 MOP | 3,925.59 MOP |
| 150 - 225 | 51.033 MOP | 3,827.45 MOP |
| 300+ | 50.247 MOP | 3,768.56 MOP |
