Technical Documents
Specifications
Brand
SamtecNumber of Contacts
9
Product Type
PCB Socket
Number of Rows
1
Sub Type
Board-to-Board
Pitch
2.54mm
Current
5.5A
Termination Type
Solder
Housing Material
Black Glass Filled Polyester
Mount Type
Through Hole
Orientation
Vertical
Connector System
Board-to-Board
Voltage
400V
Series
CES
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
105°C
Contact Material
Phosphor Bronze
Contact Plating
Tin
Standards/Approvals
RoHS
Product Details
The Samtec CES-109-01-T-S is a CES series low profile socket strip. This socket strip has dual leaf contact system. Also it has single and double row up to 100 pins.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
221.40 MOP
9.226 MOP Each (In a Tube of 24) (ex VAT)
24
221.40 MOP
9.226 MOP Each (In a Tube of 24) (ex VAT)
Stock information temporarily unavailable.
24
| quantity | Unit price | Per Tube |
|---|---|---|
| 24 - 24 | 9.226 MOP | 221.43 MOP |
| 48 - 72 | 8.996 MOP | 215.91 MOP |
| 96+ | 8.858 MOP | 212.58 MOP |
