Technical Documents
Specifications
Brand
SamtecNumber of Contacts
10
Product Type
PCB Socket
Number of Rows
2
Sub Type
Reliable Dual Wipe Socket Strip
Pitch
1.27mm
Current
3.4A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Surface
Orientation
Straight
Connector System
Board-to-Board
Voltage
395V
Series
CLP
Minimum Operating Temperature
-55°C
Row Pitch
1.27mm
Maximum Operating Temperature
125°C
Contact Material
Phosphor Bronze
Contact Plating
Gold
Standards/Approvals
No
Product Details
The Samtec CLP series 1.27mm low profile dual wipe socket has 5 positions and surface mount lead style. It has 0.000254mm gold in contact area and 0.0000762mm on tail.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
33,439.50 MOP
24.32 MOP Each (On a Reel of 1375) (ex VAT)
1375
33,439.50 MOP
24.32 MOP Each (On a Reel of 1375) (ex VAT)
Stock information temporarily unavailable.
1375
| quantity | Unit price | Per Reel |
|---|---|---|
| 1375 - 5500 | 24.32 MOP | 33,439.52 MOP |
| 6875+ | 21.888 MOP | 30,095.55 MOP |
