Technical Documents
Specifications
Brand
SamtecNumber of Contacts
60
Product Type
PCB Socket
Sub Type
Board-to-Board
Number of Rows
2
Current
2.2A
Pitch
0.8mm
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Surface
Orientation
Vertical
Stacking Height
18mm
Connector System
Board-to-Board
Voltage
318V
Series
ERF8
Row Pitch
4.5mm
Minimum Operating Temperature
-55°C
Contact Material
Beryllium Copper Alloy
Contact Plating
Gold
Maximum Operating Temperature
125°C
Standards/Approvals
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
36,800.80 MOP
98.135 MOP Each (On a Reel of 375) (ex VAT)
375
36,800.80 MOP
98.135 MOP Each (On a Reel of 375) (ex VAT)
Stock information temporarily unavailable.
375
| quantity | Unit price | Per Reel |
|---|---|---|
| 375 - 375 | 98.135 MOP | 36,800.80 MOP |
| 750 - 1125 | 95.682 MOP | 35,880.77 MOP |
| 1500+ | 94.21 MOP | 35,328.74 MOP |
