Technical Documents
Specifications
Brand
SamtecNumber of Contacts
80
Product Type
PCB Socket
Number of Rows
2
Sub Type
High Speed Socket Strip
Pitch
0.8mm
Current
2.2A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Surface
Orientation
Straight
Stacking Height
18mm
Connector System
Board-to-Board
Voltage
318V
Series
ERF8
Minimum Operating Temperature
-55°C
Row Pitch
4.5mm
Maximum Operating Temperature
125°C
Contact Material
Beryllium Copper Alloy
Contact Plating
Gold
Standards/Approvals
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
25,371.20 MOP
84.571 MOP Each (On a Reel of 300) (ex VAT)
300
25,371.20 MOP
84.571 MOP Each (On a Reel of 300) (ex VAT)
Stock information temporarily unavailable.
300
| quantity | Unit price | Per Reel |
|---|---|---|
| 300 - 1200 | 84.571 MOP | 25,371.18 MOP |
| 1500+ | 76.114 MOP | 22,834.07 MOP |
