Technical Documents
Specifications
Brand
SamtecProduct Type
PCB Header
Series
ERM8
Pitch
0.8mm
Current
2.2A
Number of Contacts
80
Housing Material
Liquid Crystal Polymer
Number of Rows
2
Orientation
Straight
Shrouded/Unshrouded
Shrouded
Mount Type
Surface
Connector System
Board-to-Board
Contact Material
Phosphor Bronze
Contact Plating
Gold
Minimum Operating Temperature
-55°C
Row Pitch
0.8mm
Termination Type
Solder
Contact Gender
Male
Maximum Operating Temperature
125°C
Standards/Approvals
No
Voltage
318V
Country of Origin
Costa Rica
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
10,767.30 MOP
86.138 MOP Each (On a Reel of 125) (ex VAT)
125
10,767.30 MOP
86.138 MOP Each (On a Reel of 125) (ex VAT)
Stock information temporarily unavailable.
125
| quantity | Unit price | Per Reel |
|---|---|---|
| 125 - 125 | 86.138 MOP | 10,767.29 MOP |
| 250 - 375 | 83.985 MOP | 10,498.12 MOP |
| 500+ | 82.693 MOP | 10,336.60 MOP |
