Technical Documents
Specifications
Brand
SamtecNumber of Contacts
30
Product Type
PCB Socket
Number of Rows
2
Sub Type
Cost-Effective Single Beam Socket Strip
Pitch
1.27mm
Current
2.9A
Housing Material
Liquid Crystal Polymer
Termination Type
Solder
Mount Type
Surface
Orientation
Vertical
Connector System
Board-to-Board
Series
FLE
Minimum Operating Temperature
-55°C
Row Pitch
1.27mm
Contact Plating
Gold
Maximum Operating Temperature
125°C
Contact Material
Phosphor Bronze
Standards/Approvals
RoHS
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
47,600.00 MOP
52.889 MOP Each (On a Reel of 900) (ex VAT)
900
47,600.00 MOP
52.889 MOP Each (On a Reel of 900) (ex VAT)
Stock information temporarily unavailable.
900
| quantity | Unit price | Per Reel |
|---|---|---|
| 900 - 3600 | 52.889 MOP | 47,600.03 MOP |
| 4500+ | 47.60 MOP | 42,840.05 MOP |
