Technical Documents
Specifications
Brand
SamtecNumber of Contacts
24
Product Type
PCB Socket
Number of Rows
2
Sub Type
High Reliability Flexible Pin Count Socket Strip
Pitch
1.27mm
Current
2.9A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Surface
Orientation
Straight
Connector System
Board-to-Board
Voltage
310V
Series
SFMC
Minimum Operating Temperature
-55°C
Row Pitch
1.27mm
Contact Gender
Female
Maximum Operating Temperature
125°C
Contact Material
Beryllium Copper Alloy
Contact Plating
Gold
Standards/Approvals
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
2,016.30 MOP
54.493 MOP Each (In a Tube of 37) (ex VAT)
37
2,016.30 MOP
54.493 MOP Each (In a Tube of 37) (ex VAT)
Stock information temporarily unavailable.
37
| quantity | Unit price | Per Tube |
|---|---|---|
| 37 - 37 | 54.493 MOP | 2,016.26 MOP |
| 74 - 111 | 53.131 MOP | 1,965.84 MOP |
| 148+ | 52.313 MOP | 1,935.60 MOP |
