Technical Documents
Specifications
Brand
SamtecNumber of Contacts
8
Product Type
PCB Socket
Number of Rows
2
Sub Type
Board-to-Board
Pitch
2mm
Current
3.2A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Surface
Orientation
Straight
Connector System
Board-to-Board
Series
TLE
Minimum Operating Temperature
-55°C
Row Pitch
2mm
Contact Plating
Gold
Contact Gender
Female
Maximum Operating Temperature
125°C
Contact Material
Phosphor Bronze
Standards/Approvals
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
15,097.10 MOP
20.13 MOP Each (On a Reel of 750) (ex VAT)
750
15,097.10 MOP
20.13 MOP Each (On a Reel of 750) (ex VAT)
Stock information temporarily unavailable.
750
| quantity | Unit price | Per Reel |
|---|---|---|
| 750 - 750 | 20.13 MOP | 15,097.13 MOP |
| 1500 - 2250 | 19.626 MOP | 14,719.66 MOP |
| 3000+ | 19.324 MOP | 14,493.26 MOP |
