Technical Documents
Specifications
Brand
SamtecProduct Type
Pin Header
Series
TSM
Pitch
2.54mm
Current
5.4A
Number of Contacts
4
Housing Material
Liquid Crystal Polymer
Number of Rows
1
Orientation
Horizontal
Shrouded/Unshrouded
Unshrouded
Connector System
Board-to-Board
Mount Type
Surface
Contact Material
Phosphor Bronze
Contact Plating
Gold
Minimum Operating Temperature
-55°C
Row Pitch
2.54mm
Termination Type
Solder
Contact Gender
Male
Maximum Operating Temperature
125°C
Standards/Approvals
No
Voltage
475V
Product Details
The Samtec TSM series SMT board-to-board square post header terminal strip with a 2.54mm pitch, which has 4 contact, a black liquid crystal polymer insulator and phosphor bronze terminal. It used 0.25 μm gold on post and matte tin on tail and has single r
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
3,252.30 MOP
4.818 MOP Each (On a Reel of 675) (ex VAT)
675
3,252.30 MOP
4.818 MOP Each (On a Reel of 675) (ex VAT)
Stock information temporarily unavailable.
675
| quantity | Unit price | Per Reel |
|---|---|---|
| 675 - 2700 | 4.818 MOP | 3,252.26 MOP |
| 3375 - 6075 | 4.649 MOP | 3,138.18 MOP |
| 6750+ | 4.417 MOP | 2,981.24 MOP |
