Technical Documents
Specifications
Brand
SamtecProduct Type
Pin Header
Series
TSM
Current
5.4A
Pitch
2.54mm
Number of Contacts
4
Housing Material
Liquid Crystal Polymer
Number of Rows
2
Orientation
Vertical
Shrouded/Unshrouded
Unshrouded
Connector System
Board-to-Board
Mount Type
Surface
Contact Material
Phosphor Bronze
Contact Plating
Gold
Row Pitch
2.54mm
Termination Type
Solder
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
125°C
Contact Gender
Male
Standards/Approvals
No
Voltage
475V
Product Details
The Samtec TSM series is a surface mount terminal strip. Insulating material used is of Black liquid crystal polymer. Terminals are of phosphor bronze. There are total 4 no. of contacts.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
10.30 MOP
10.30 MOP Each (ex VAT)
1
10.30 MOP
10.30 MOP Each (ex VAT)
Stock information temporarily unavailable.
1
| quantity | Unit price |
|---|---|
| 1 - 9 | 10.30 MOP |
| 10 - 99 | 9.89 MOP |
| 100 - 249 | 9.48 MOP |
| 250+ | 9.27 MOP |
