Technical Documents
Specifications
Brand
SemtechDiode Configuration
Complex Array
Product Type
TVS Diode
Direction Type
Uni-Directional
Minimum Breakdown Voltage Vbr
3.5V
Mount Type
Surface
Package Type
SOT-23
Maximum Reverse Stand-off Voltage Vwm
3.3V
Pin Count
6
Peak Pulse Power Dissipation Pppm
100W
Clamping Voltage VC
9.5V
Minimum Operating Temperature
-55°C
Test Current It
2μA
Maximum Peak Pulse Current Ippm
10A
ESD Protection
Yes
Number of Elements per Chip
4
Maximum Operating Temperature
125°C
Height
1.3mm
Length
3mm
Standards/Approvals
No
Width
1.75mm
Series
SMS
Maximum Reverse Leakage Current
500nA
Automotive Standard
No
Country of Origin
China
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
77.60 MOP
7.76 MOP Each (Supplied on a Reel) (ex VAT)
Production pack (Reel)
10
77.60 MOP
7.76 MOP Each (Supplied on a Reel) (ex VAT)
Stock information temporarily unavailable.
Production pack (Reel)
10
| quantity | Unit price | Per Reel |
|---|---|---|
| 10 - 740 | 7.76 MOP | 77.60 MOP |
| 750 - 1490 | 7.554 MOP | 75.54 MOP |
| 1500+ | 7.44 MOP | 74.40 MOP |
