Technical Documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
6A
Product Type
TRIAC
Mount Type
Through Hole
Package Type
TO-220
Maximum Gate Trigger Current Igt
50mA
Repetitive Peak Reverse Voltage VDRM
800V
Surge Current Rating
63A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1.3V
Maximum Holding Current Ih
50mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
125°C
Height
15.9mm
Length
10.4mm
Standards/Approvals
No
Repetitive Peak Off-State Current
1mA
Peak On-State Voltage
1.55V
Automotive Standard
No
Country of Origin
China
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
60.50 MOP
6.049 MOP Each (In a Pack of 10) (ex VAT)
Standard
10
60.50 MOP
6.049 MOP Each (In a Pack of 10) (ex VAT)
Stock information temporarily unavailable.
Standard
10
| quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 10 | 6.049 MOP | 60.49 MOP |
| 20 - 20 | 5.905 MOP | 59.05 MOP |
| 30+ | 5.802 MOP | 58.02 MOP |
