Technical Documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
25A
Product Type
TRIAC
Mount Type
Through Hole
Package Type
TOP
Maximum Gate Trigger Current Igt
100mA
Repetitive Peak Reverse Voltage VDRM
800V
Surge Current Rating
260A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1.3V
Maximum Holding Current Ih
80mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
125°C
Height
21.1mm
Length
15.5mm
Standards/Approvals
No
Repetitive Peak Off-State Current
3mA
Peak On-State Voltage
1.55V
Automotive Standard
No
Country of Origin
Philippines
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
246.10 MOP
49.217 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
5
246.10 MOP
49.217 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
5
| quantity | Unit price | Per Tube |
|---|---|---|
| 5 - 5 | 49.217 MOP | 246.08 MOP |
| 10 - 10 | 47.733 MOP | 238.66 MOP |
| 15+ | 46.29 MOP | 231.45 MOP |
