STMicroelectronics, Voltage Regulator 5.5V DFN 6-Pin

Name: STMicroelectronics, Voltage Regulator 5.5V DFN 6-Pin
Brand: STMicroelectronics
SKU: 1924612
Availability: LimitedAvailability

RS Stock No.: 192-4612Brand: STMicroelectronicsManufacturers Part No.: LD56100DPU30R

View all in Voltage Regulators

Technical Documents

Specifications

Brand

STMicroelectronics

Product Type

Voltage Regulator

Package Type

DFN

Mount Type

Surface

Polarity

Positive

Quiescent Current

155μA

Pin Count

Length

1.6mm

Height

0.45mm

Standards/Approvals

Width

1.2mm

Series

LD56100

Maximum Operating Temperature

125°C

Maximum Input Voltage

5.5V

Minimum Input Voltage

1.8V

Automotive Standard

Country of Origin

China

Product Details

Input voltage from 1.8 to 5.5 V
Ultra-low dropout voltage (120 mV typ. at 1 A load and VOUT = 3.3 V)
Very low quiescent current (100 μA typ. at no-load, 0.03 μA typ. in off mode)
Output voltage tolerance: ± 1% from -40 °C to +85 °C
Ultra-low Noise: 13 μV RMS Noise from 10 Hz to 100 kHz at VOUT = 3.0 V
High PSRR (70 dB@1 kHz)
Wide range of output voltages available on request: from 1.0 V up to 5.0 V in 50 mV step
Logic-controlled electronic shutdown
Internal soft-start
Optional output voltage discharge feature
Compatible with ceramic capacitor COUT = 1 μF
Internal current limit foldback and thermal protections
Available in DFN8 (1.2x1.6 mm)
Operating temperature range: -40 °C to 125 °C
