Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Serial EEPROM
Memory Size
4kB
Interface Type
Serial-I2C
Package Type
UFDFPN-5
Mount Type
Surface
Pin Count
5
Maximum Clock Frequency
400kHz
Organisation
512 k x 8 Bit
Minimum Supply Voltage
1.7V
Number of Bits per Word
8
Maximum Supply Voltage
5.5V
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Height
0.55mm
Length
1.7mm
Standards/Approvals
No
Width
1.4mm
Series
M24C04-F
Data Retention
40year
Maximum Random Access Time
900ns
Automotive Standard
AEC-Q100
Number of Words
512K
Product Details
The STMicroelectronics EEPROM is a 4-Kbit I2C-compatible EEPROM organized as 512 x 8 bits. It has a supply voltage from 1.6 V to 5.5 V. It operates with a clock frequency of 400 kHz, over an ambient temperature range of -40 °C / +85 °C.
Stock information temporarily unavailable.
6,608.10 MOP
1.322 MOP Each (On a Reel of 5000) (ex VAT)
5000
6,608.10 MOP
1.322 MOP Each (On a Reel of 5000) (ex VAT)
Stock information temporarily unavailable.
5000
| quantity | Unit price | Per Reel |
|---|---|---|
| 5000 - 5000 | 1.322 MOP | 6,608.08 MOP |
| 10000 - 10000 | 1.282 MOP | 6,409.92 MOP |
| 15000+ | 1.244 MOP | 6,217.73 MOP |
Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Serial EEPROM
Memory Size
4kB
Interface Type
Serial-I2C
Package Type
UFDFPN-5
Mount Type
Surface
Pin Count
5
Maximum Clock Frequency
400kHz
Organisation
512 k x 8 Bit
Minimum Supply Voltage
1.7V
Number of Bits per Word
8
Maximum Supply Voltage
5.5V
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Height
0.55mm
Length
1.7mm
Standards/Approvals
No
Width
1.4mm
Series
M24C04-F
Data Retention
40year
Maximum Random Access Time
900ns
Automotive Standard
AEC-Q100
Number of Words
512K
Product Details
The STMicroelectronics EEPROM is a 4-Kbit I2C-compatible EEPROM organized as 512 x 8 bits. It has a supply voltage from 1.6 V to 5.5 V. It operates with a clock frequency of 400 kHz, over an ambient temperature range of -40 °C / +85 °C.
