STMicroelectronics, 32 kB EEPROM, 450 ns 8-Pin SOIC Serial-I2C

Name: STMicroelectronics, 32 kB EEPROM, 450 ns 8-Pin SOIC Serial-I2C
Brand: STMicroelectronics
SKU: 1906766
Availability: LimitedAvailability

RS Stock No.: 190-6766Brand: STMicroelectronicsManufacturers Part No.: M24C32-FMN6TP

View all in EEPROM

Technical Documents

Specifications

Brand

STMicroelectronics

Memory Size

32kB

Product Type

EEPROM

Interface Type

Serial-I2C

Package Type

SOIC

Mount Type

Surface

Pin Count

Organisation

4k x 8 Bit

Maximum Clock Frequency

1MHz

Minimum Supply Voltage

1.7V

Number of Bits per Word

Maximum Supply Voltage

5.5V

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

Height

1.75mm

Length

5mm

Standards/Approvals

RoHS 2011/65/EU

Width

150mm

Series

M24C32-F

Data Retention

200year

Supply Current

2.5mA

Maximum Random Access Time

450ns

Automotive Standard

AEC-Q100

Number of Words

Product Details

Compatible with all I2C bus modes:
1 MHz
400 kHz
100 kHz
Memory array:
32 Kbit (4 Kbyte) of EEPROM
Page size: 32 byte
Additional Write lockable page
Single supply voltage:
1.7 V to 5.5 V over –40 °C / +85 °C
1.6 V to 5.5 V over –20 °C / +85 °C
Write:
Byte Write within 5 ms
Page Write within 5 ms
Random and sequential Read modes
Write protect of the whole memory array
Enhanced ESD/Latch-Up protection
More than 4 million Write cycles
More than 200-years data retention
Packages
PDIP8
SO8
TSSOP8
UFDFPN8
WLCSP
UFDFPN5
Unsawn wafer (each die is tested)

View all in EEPROM

Stock information temporarily unavailable.

4,601.20 MOP

1.84 MOP Each (On a Reel of 2500) (ex VAT)

STMicroelectronics, 32 kB EEPROM, 450 ns 8-Pin SOIC Serial-I2C

4,601.20 MOP

1.84 MOP Each (On a Reel of 2500) (ex VAT)

STMicroelectronics, 32 kB EEPROM, 450 ns 8-Pin SOIC Serial-I2C

Stock information temporarily unavailable.

quantity	Unit price	Per Reel
2500 - 2500	1.84 MOP	4,601.18 MOP
5000 - 7500	1.794 MOP	4,486.18 MOP
10000+	1.767 MOP	4,417.24 MOP
