Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
MOSFET
Channel Type
Type N
Maximum Continuous Drain Current Id
10A
Maximum Drain Source Voltage Vds
600V
Package Type
TO-220
Series
MDmesh
Mount Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance Rds
550mΩ
Channel Mode
Enhancement
Typical Gate Charge Qg @ Vgs
19nC
Maximum Power Dissipation Pd
25W
Minimum Operating Temperature
-55°C
Forward Voltage Vf
1.3V
Maximum Operating Temperature
150°C
Length
10.4mm
Height
16.4mm
Standards/Approvals
No
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
122.50 MOP
24.505 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
5
122.50 MOP
24.505 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
5
| quantity | Unit price | Per Tube |
|---|---|---|
| 5 - 10 | 24.505 MOP | 122.53 MOP |
| 15 - 20 | 23.908 MOP | 119.54 MOP |
| 25+ | 23.516 MOP | 117.58 MOP |
