Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Microcontroller
Series
STM32L072RZ
Package Type
LQFP
Mount Type
Surface
Pin Count
64
Device Core
ARM Cortex M0+
Data Bus Width
32bit
Program Memory Size
192kB
Maximum Clock Frequency
32MHz
RAM Size
20kB
Maximum Supply Voltage
3.6V
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Maximum Power Dissipation Pd
435mW
Number of Programmable I/Os
84
DACs
2 x 12 Bit
Height
1.45mm
Analogue Comparators
2
Length
10mm
Standards/Approvals
No
Minimum Supply Voltage
1.65V
Instruction Set Architecture
RISC
Automotive Standard
No
ADCs
16 x 12 Bit
Program Memory Type
FLASH
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
7,304.40 MOP
45.652 MOP Each (In a Tray of 160) (ex VAT)
160
7,304.40 MOP
45.652 MOP Each (In a Tray of 160) (ex VAT)
Stock information temporarily unavailable.
160
| quantity | Unit price | Per Tray |
|---|---|---|
| 160 - 640 | 45.652 MOP | 7,304.39 MOP |
| 800+ | 44.283 MOP | 7,085.20 MOP |
