Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
MOSFET
Channel Type
Type N
Maximum Continuous Drain Current Id
21A
Maximum Drain Source Voltage Vds
500V
Series
MDmesh
Package Type
TO-220
Mount Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance Rds
158mΩ
Channel Mode
Enhancement
Typical Gate Charge Qg @ Vgs
50nC
Minimum Operating Temperature
-55°C
Forward Voltage Vf
1.5V
Maximum Power Dissipation Pd
150W
Maximum Operating Temperature
150°C
Height
15.75mm
Standards/Approvals
No
Length
10.4mm
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
58.60 MOP
58.64 MOP Each (ex VAT)
Standard
1
58.60 MOP
58.64 MOP Each (ex VAT)
Stock information temporarily unavailable.
Standard
1
| quantity | Unit price |
|---|---|
| 1 - 12 | 58.64 MOP |
| 13 - 24 | 57.09 MOP |
| 25+ | 56.27 MOP |
