Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Diode
Mount Type
Surface
Package Type
DO-216AA
Maximum Continuous Forward Current If
1A
Peak Reverse Repetitive Voltage Vrrm
40V
Diode Configuration
Single
Series
STPS1L40M
Rectifier Type
Schottky
Pin Count
2
Peak Reverse Current Ir
4mA
Maximum Forward Voltage Vf
600mV
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
50A
Maximum Operating Temperature
150°C
Length
2.05mm
Height
1.1mm
Standards/Approvals
No
Automotive Standard
No
