Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Diode
Mount Type
Surface
Package Type
TO-263
Maximum Continuous Forward Current If
10A
Peak Reverse Repetitive Voltage Vrrm
650V
Diode Configuration
Single
Rectifier Type
Switching
Pin Count
3
Peak Reverse Current Ir
425μA
Minimum Operating Temperature
-40°C
Peak Non-Repetitive Forward Surge Current Ifsm
470A
Maximum Forward Voltage Vf
2.5V
Maximum Operating Temperature
175°C
Height
4.4mm
Length
10mm
Standards/Approvals
No
Automotive Standard
AEC-Q101
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
67.60 MOP
33.80 MOP Each (In a Pack of 2) (ex VAT)
Standard
2
67.60 MOP
33.80 MOP Each (In a Pack of 2) (ex VAT)
Stock information temporarily unavailable.
Standard
2
| quantity | Unit price | Per Pack |
|---|---|---|
| 2 - 248 | 33.80 MOP | 67.60 MOP |
| 250 - 498 | 32.924 MOP | 65.85 MOP |
| 500+ | 32.409 MOP | 64.82 MOP |
