Technical Documents
Specifications
Brand
STMicroelectronicsDiode Configuration
Single
Product Type
Switching Diode
Maximum Forward Current If
8A
Sub Type
Silicon Junction
Mount Type
Through Hole
Package Type
TO-220
Pin Count
2
Peak Reverse Recovery Time trr
47ns
Maximum Peak Reverse Repetitive Voltage Vrrm
1200V
Maximum Forward Voltage Vf
2.2V
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
60A
Maximum Operating Temperature
175°C
Length
10.4mm
Height
16.4mm
Standards/Approvals
No
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
50.50 MOP
10.099 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
5
50.50 MOP
10.099 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
5
| quantity | Unit price | Per Tube |
|---|---|---|
| 5 - 10 | 10.099 MOP | 50.49 MOP |
| 15 - 20 | 9.893 MOP | 49.46 MOP |
| 25+ | 9.769 MOP | 48.85 MOP |
