Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
MOSFET
Channel Type
Type N
Maximum Continuous Drain Current Id
17.5A
Maximum Drain Source Voltage Vds
950V
Package Type
TO-247
Series
MDmesh, SuperMESH
Mount Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance Rds
330mΩ
Channel Mode
Enhancement
Typical Gate Charge Qg @ Vgs
40nC
Maximum Power Dissipation Pd
250W
Minimum Operating Temperature
-55°C
Forward Voltage Vf
1.5V
Maximum Operating Temperature
150°C
Length
15.75mm
Height
20.15mm
Standards/Approvals
No
Automotive Standard
No
Country of Origin
China
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
289.10 MOP
57.811 MOP Each (In a Pack of 5) (ex VAT)
Standard
5
289.10 MOP
57.811 MOP Each (In a Pack of 5) (ex VAT)
Stock information temporarily unavailable.
Standard
5
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 5 | 57.811 MOP | 289.06 MOP |
| 10 - 10 | 56.368 MOP | 281.84 MOP |
| 15+ | 55.482 MOP | 277.41 MOP |
