Technical Documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
12A
Product Type
TRIAC
Mount Type
Through Hole
Package Type
TO-220
Maximum Gate Trigger Current Igt
35mA
Repetitive Peak Reverse Voltage VDRM
600V
Surge Current Rating
126A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1V
Maximum Holding Current Ih
35mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
150°C
Height
15.9mm
Length
10.4mm
Standards/Approvals
No
Repetitive Peak Off-State Current
3.9mA
Peak On-State Voltage
1.5V
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
86.90 MOP
17.374 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
5
86.90 MOP
17.374 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
5
| quantity | Unit price | Per Tube |
|---|---|---|
| 5 - 20 | 17.374 MOP | 86.87 MOP |
| 25 - 95 | 17.065 MOP | 85.32 MOP |
| 100 - 245 | 16.756 MOP | 83.78 MOP |
| 250 - 495 | 16.447 MOP | 82.23 MOP |
| 500+ | 16.138 MOP | 80.69 MOP |
