Technical Documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
16A
Product Type
TRIAC
Mount Type
Through Hole
Package Type
TO-220
Maximum Gate Trigger Current Igt
10mA
Repetitive Peak Reverse Voltage VDRM
600V
Surge Current Rating
168A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1.3V
Maximum Holding Current Ih
15mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
150°C
Height
15.9mm
Length
10.4mm
Standards/Approvals
No
Repetitive Peak Off-State Current
2mA
Peak On-State Voltage
1.55V
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
70.10 MOP
14.015 MOP Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
5
70.10 MOP
14.015 MOP Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
5
| quantity | Unit price | Per Tube |
|---|---|---|
| 5 - 10 | 14.015 MOP | 70.07 MOP |
| 15 - 20 | 13.685 MOP | 68.42 MOP |
| 25+ | 13.458 MOP | 67.29 MOP |
