Technical Documents
Specifications
Brand
Taiwan SemiconductorDiode Configuration
Single
Product Type
TVS Diode
Direction Type
Bi-Directional
Minimum Breakdown Voltage Vbr
31.1V
Mount Type
Through Hole
Package Type
DO-15
Maximum Reverse Stand-off Voltage Vwm
28V
Pin Count
2
Peak Pulse Power Dissipation Pppm
500W
Clamping Voltage VC
45.4V
Minimum Operating Temperature
-55°C
Test Current It
1mA
Maximum Peak Pulse Current Ippm
11.5A
Number of Elements per Chip
1
Maximum Operating Temperature
175°C
Height
3.6mm
Length
7.6mm
Diameter
3.6mm
Standards/Approvals
No
Width
3.6mm
Series
SA
Maximum Reverse Leakage Current
1μA
Automotive Standard
AEC-Q101
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
62.70 MOP
3.133 MOP Each (In a Pack of 20) (ex VAT)
Standard
20
62.70 MOP
3.133 MOP Each (In a Pack of 20) (ex VAT)
Stock information temporarily unavailable.
Standard
20
| quantity | Unit price | Per Pack |
|---|---|---|
| 20 - 860 | 3.133 MOP | 62.65 MOP |
| 880 - 1740 | 3.055 MOP | 61.11 MOP |
| 1760+ | 3.004 MOP | 60.08 MOP |
