Technical Documents
Specifications
Brand
TE ConnectivityNumber of Contacts
3
Product Type
Pluggable Terminal Block
Pitch
5mm
Number of Rows
1
Current
16A
Minimum Wire Size mm²
0.13mm²
Housing Material
Brass
Connector Gender
Male
Maximum Wire Size mm²
3.31mm²
Minimum Wire Size AWG
26AWG
Maximum Wire Size AWG
12AWG
Orientation
Vertical
Wire Connection Method
Spring
Colour
Green
Voltage
300V ac
Length
15mm
Depth
16.1mm
Standards/Approvals
No
Width
15mm
Product Details
Terminal blocks and strips are insulated connections that fasten two or more wires together and consist of an insulating frame and a clamping system. TEs Terminal blocks and strips offer a reliable connection with a large variety of technologies and ranges to serve many industrial applications from control to power distribution.
TE Connectivity is expanding its Buchanan portfolio with Push-in clamp termination PCB Connectors to enable tool-less wire insertion of ferruled and unferruled wires. This saves up to 80% installation labor time vs. traditional screw-clamp termination, leading to important cost savings. The design of the PCB Connectors in 3.5 mm and 5.0 mm pitch consists of two-piece plug connectors with mating straight and right angle shrouded headers. TE engineers have designed this product range for use in control system applications to suit high density signal and power applications.
Stock information temporarily unavailable.
3,972.40 MOP
19.862 MOP Each (In a Box of 200) (ex VAT)
200
3,972.40 MOP
19.862 MOP Each (In a Box of 200) (ex VAT)
Stock information temporarily unavailable.
200
| quantity | Unit price | Per Box |
|---|---|---|
| 200 - 200 | 19.862 MOP | 3,972.37 MOP |
| 400 - 600 | 19.465 MOP | 3,892.92 MOP |
| 800+ | 18.881 MOP | 3,776.16 MOP |
