Technical Documents
Specifications
Brand
Texas InstrumentsProduct Type
Inverter
Logic Function
Inverter
Input Type
Schmitt Trigger
Output Type
CMOS
Number of Elements per Chip
6
Schmitt Trigger Input
Yes
Maximum Propagation Delay Time @ CL
280ns
Maximum High Level Output Current
-4.2mA
Maximum Low Level Output Current
4.2mA
Minimum Supply Voltage
3V
Mount Type
Through Hole
Package Type
CDIP
Maximum Supply Voltage
18V
Pin Count
14
Minimum Operating Temperature
-55°C
Logic Family
4000
Maximum Operating Temperature
125°C
Height
3.56mm
Length
19.94mm
Standards/Approvals
No
Series
CD40106B
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
286.30 MOP
286.27 MOP Each (ex VAT)
Standard
1
286.30 MOP
286.27 MOP Each (ex VAT)
Stock information temporarily unavailable.
Standard
1
